FPSO MIAMTE MV34

  • FPSO
  • 32 m
  • Tower Yoke
  • EPCI
  • Lease
  • O&M
FPSO MIAMTE MV34

The FPSO will be deployed in the Offshore Area 1 some 10 km off the coast of Mexico at a water depth approximately 32 m.

MODEC is responsible for the engineering, procurement, construction, mobilization, installation and operation of the FPSO, including topsides processing equipment as well as hull and marine systems. SOFEC, Inc., a MODEC group company, will design and supply the disconnectable tower yoke mooring system of the FPSO.

The FPSO will be capable of processing 90,000 barrels of crude oil per day, 75 million cubic feet of gas per day, 120,000 barrels of water injection per day and have a storage capacity of 900,000 barrels of crude oil. The first oil production by the FPSO is planned for 2021.

MODEC will own the FPSO and provide the operations and maintenance services for an initial 15 year period with the option of one-year extensions for a further 5 years.

Unit Name
FPSO MIAMTE MV34
Field
Area 1 field
Country
Mexico
Water Depth
32m
Mooring Type
SOFEC Disconnectable Tower Yoke
Storage Capacity
700,000 bbls
Oil Production
90,000 bopd
Gas Production
75 mmscfd
Produced water re-injection
120,000 bwpd
Client
Eni Mexico S. de R.L. de C.V.
Contract
EPCI + Time Charter
Scope of Work
Engineering, Procurement, Construction, Mobilization, Installation, Operation & Maintenance
First Oil
Planned 2021
Charter Period
15 years + 5 one-year extension options
Current Status
Under Construction (MODEC will own and operate)
