HOME Projects Mooring Solutions Projects Mooring Solutions Projects By Region By Type By Region Africa Americas Asia Pacific Europe Middle East FPSO Sangomar External Turret[PDF：154KB] SOFEC will design, construct, and fabricate an external turret for the Sangomar (formerly SNE) Field Development Phase 1 project located in the Sangomar Offshore and Sangomar Offshore Deep oil blocks, located offshore Senegal. Dangote CALM Buoys SPM-C1 & SPM-C2[PDF：693KB] SOFEC was responsible for the engineering, procurement and construction of five (5) CALM Buoys and associated anchor chain legs, PLEMs, piles, hoses, mooring hawsers, and all ancillaries in accordance with Oil Companies International Maine Forum (OCIMF) Guidelines. Dangote CALM Buoys SPM-P1, SPM-P2 & SPM-P3[PDF：668KB] SOFEC was responsible for the engineering, procurement and construction of five (5) CALM Buoys and associated anchor chain legs, PLEMs, piles, hoses, mooring hawsers, and all ancillaries in accordance with Oil Companies International Maine Forum (OCIMF) Guidelines. FPSO Prof. John Evans Atta Mills External Turret[PDF：794KB] SOFEC designed and fabricated an external mooring system for the FPSO Prof. John Evans Atta Mills (Tullow TEN) and also assisted with the installation and commissioning. The FPSO is located in the Tweneboa, Enyenra, and Ntomme (TEN) fields offshore Ghana. FPSO Kwame Nkrumah MV21 External Turret[PDF：672KB] SOFEC designed, constructed, fabricated and delivered an external turret mooring system for a 272,000 dwt MODEC-converted FPSO. This is the first FPSO installed on the Jubilee Field, one of the largest oil fields discovered in West Africa in the past decade. This is one of the largest external turrets on an FPSO application. FPSO PSVM External Turret[PDF：505KB] SOFEC designed, constructed, fabricated and installed an external turret mooring system complete with anchor legs, fluid swivels and installation aids. FPSO PazFlor Spread Mooring[PDF：427KB] SOFEC designed spread mooring piles, mooring legs, pull-in and installation equipment for the FPSO. Sonatrach Skikda #1 & #2 CALMs[PDF：404KB] In December of 2002 SOFEC was awarded design, supply and installation of five offshore loading stations for transportation of crude oil and condensate from onshore facilities for Sonatrach TRC, the Oil and Gas Company, in Algeria. FPSO Baobab Ivoirien MV10 External Turret[PDF：444KB] SOFEC designed and constructed an external turret mooring system to moor a 357,000 dwt MODEC-converted FPSO in 970m water depth. FPSO Kizomba B Spread Mooring[PDF：303KB] Contracted through Hyundai Heavy Industries, SOFEC was responsible for the design and analysis of the Kizomba B FPSO spread mooring system. Sonatrach Bejaia CALM[PDF：588KB] In December of 2002 SOFEC was awarded design, supply and installation of five offshore loading stations for transportation of crude oil and condensate from onshore facilities for Sonatrach TRC, the Oil and Gas Company, in Algeria. Sonatrach Arzew #1 & #2 CALMs[PDF：465KB] In December of 2002 SOFEC was awarded design, supply and installation of five offshore loading stations for transportation of crude oil and condensate from onshore facilities for Sonatrach TRC, the Oil and Gas Company, in Algeria. FPSO Kizomba A Spread Mooring[PDF：283KB] SOFEC was responsible for the design and analysis of the SOFEC spread mooring system for the world’s largest FPSO. FSO Kome-Kribi 1 Tower Yoke[PDF：651KB] SOFEC designed and provided project management for a tower yoke mooring system for a 357,000 dwt MODEC-converted ULCC tanker for the Chad development project offshore Cameroon, West Africa. FSO Madiela Spread Mooring[PDF：432KB] SOFEC designed and supplied the 12-leg anchoring system and deckmounted equipment including chain supports and jacking system for a permanent spread mooring system for installation on a MODEC converted 139,000 dwt FSO vessel. FPSO Jamestown Spread Mooring[PDF：581KB] SOFEC designed and supplied a permanent spread mooring system for installation on an Early Production System (EPS) in 112m water depth for Chevron’s Nemba Field Development off Cabinda, Angola. FSO Escravos LPG External Turret[PDF：503KB] SOFEC designed and constructed an external turret mooring system for a MODEC purpose-built FSO installed in 42m water depth. FPSO Bacalhau Spread Mooring System[PDF：154KB] SOFEC is responsible for the design and procurement of a spread mooring system for the FPSO Bacalhau, at the Bacalhau field, Block BM-S-8 located iin the giant “pre-salt” region of the Santos Basin some 185 kilometers off the coast of the municipality of Ilhabela/SP, in the state of São Paulo. FPSO Anita Garibaldi – MV33 Spread Mooring System[PDF：154KB] SOFEC is responsible for the design and procurement of a spread mooring system for the FPSO Anita Garibaldi – MV33 which will be deployed at the Marlim Field in the Campos Basin, in the northern region of the Rio de Janeiro State, 150 km off the coast. FPSO Almirante Barroso – MV32 Spread Mooring System[PDF：154KB] SOFEC is responsible for the design and procurement of a spread mooring system for the FPSO Almirante Barroso – MV32 which will be deployed at the Buzios Field of the Santos Basin, offshore Brazil. FPSO Miamte – MV34 Disconnectable Tower Yoke Mooring System[PDF：405KB] SOFEC designed, constructed, and fabricated a Disconnectable Tower Yoke Mooring System for the FPSO Eni Mexico Area 1 which is deployed in the Amoca – Area 1 Field some 10 km off the coast of Mexico. FPSO Guanabara MV31 Spread Mooring[PDF：154KB] SOFEC is responsible for the design and procurement of a spread mooring system for the FPSO Guanabara – MV31 which will be deployed at the Mero (formerly Libra) Field in Santos Basin, offshore Brazil. FPSO Carioca MV30 Spread Mooring[PDF：154KB] SOFEC is responsible for the design and procurement of a spread mooring system for the FPSO Carioca – MV30 which will be deployed at the Sépia Field in Santos Basin, offshore Brazil. FPSO Cidade de Campos dos Goytaczes MV29 Spread Mooring[PDF：607KB] SOFEC designed and procured a spread mooring system for the FPSO Cidade de Campos dos Goytaczes – MV29 located in the BM-C- 36 (Tartaruga Verde and Tartaruga Mestica fields, Campos Basin) offshore Brazil. FPSO Cidade de Caraguatatuba MV27 Spread Mooring[PDF：425KB] SOFEC designed and procured a spread mooring system for the FPSO Cidade de Caraguatatuba – MV27 which is deployed in the BM-S-9 (Carioca field, Campos Basin) offshore Brazil. FPSO Cidade de Itaguai MV26 Spread Mooring[PDF：503KB] SOFEC designed and procured a spread mooring system for the FPSO Cidade de Itaguai – MV26 which is deployed in the BM-S-11 (Lula- Iracema Norte field, Campos Basin) offshore Brazil. PEMEX Salina Cruz CALM[PDF：563KB] SOFEC designed and supplied three replacement Catenary Anchor Leg Mooring (CALM) Buoys for PEMEX REFINACIÓN in Mexico, at the Rosarito, Tuxpan and Salina Cruz. PEMEX Tuxpan CALM[PDF：506KB] SOFEC designed and supplied three replacement Catenary Anchor Leg Mooring (CALM) Buoys for PEMEX REFINACIÓN in Mexico, at the Rosarito, Tuxpan and Salina Cruz. PEMEX Rosarito CALM[PDF：495KB] SOFEC designed and supplied three replacement Catenary Anchor Leg Mooring (CALM) Buoys for PEMEX REFINACIÓN in Mexico, at the Rosarito, Tuxpan and Salina Cruz fields. PEMEX Salina Cruz 2 CALM[PDF：444KB] SOFEC designed and supplied three replacement Catenary Anchor Leg Mooring (CALM) Buoys for PEMEX REFINACIÓN in Mexico, at the Rosarito, Tuxpan and Salina Cruz fields. FSO UOTE External Turret[PDF：448KB] SOFEC designed, constructed, fabricated and delivered an external mooring system for the FSO UOTE. FPSO Cidade de Mangaratiba MV24 Spread Mooring[PDF：419KB] SOFEC designed and procured a spread mooring system for the FPSO Cidade de Mangaratiba – MV24 located in the Cernambi Sul field in Santos Basin. Barbers Point (Tesoro) CALM[PDF：433KB] SOFEC will design, construct and installea CALM terminal for crude oil, bunker fuel, gasoil, kerosene and gasoline and fuel oil. FPSO OSX 3 External Turret[PDF：453KB] SOFEC designed, constructed and supplied an external cantilevered bow turret system for a 357,000 dwt FPSO vessel. The OSX-3 FPSO is located within block BM-C-39 of the Campos Basin, offshore Brazil, on the Waikiki Pero Inga fields in 110m water depth. FPSO Cidade de Sao Paulo MV23 Spread Mooring[PDF：562KB] SOFEC designed and procured a spread mooring system for the FPSO Cidade de São Paulo – MV23 which is deployed in the Guará field in Santos Basin. FPSO Cidade de Angra dos Reis MV22 Spread Mooring[PDF：344KB] SOFEC designed and procured a spread mooring system for the FPSO Cidade de Angra dos Reis MV22 in the giant Tupi area in Brazil’s vast pre-salt reserves of the Santos Basin. FPSO Cidade de Santos MV20 Spread Mooring[PDF：509KB] SOFEC designed and procured a spread mooring system for the FPSO. NuStar CALM[PDF：553KB] SOFEC designed, constructed, and shipped a replacement CALM Buoy for the system SOFEC installed in 1994 for Statia Terminals, N.V. in Tumble Down Dick Bay on the Northwest side of the Island of St, Eustatius. Termap S.A. CALM[PDF：367KB] SOFEC will design, supply and install an interchangeable CALM Buoy system for the Caleta Olivia & Caleta Cordova fields offshore Argentina. FPSO Cidade de Niteroi MV18 Spread Mooring[PDF：532KB] SOFEC designed, provided analysis and procurement of a spread mooring system to moor a 258,000 dwt MODEC converted VLCC FPSO located in the Jubarti field of the Campos Basin offshore Brazil. FSO Cidade de Macae MV15 External Turret[PDF：336KB] SOFEC designed, constructed and supplied an external turret mooring system to moor a 350,000 dwt MODEC-converted FSO vessel to receive, store and offload oil produced by the PRA-1 Platform and nearby oil fields in the Campos Basin, Brazil. FPSO Cidade Rio de Janerio MV14 Spread Mooring[PDF：331KB] SOFEC designed and supplied the spread mooring system for a MODEC-owned 264,148 dwt FPSO located in the 1-RJS-409 / 3-RJS-415 Espadarte Sul field offshore Brazil’s Campos. OCP #1 (Charlie) CALM[PDF：469KB] SOFEC designed and supplied two CALM Buoy systems for the OCP pipeline project in Ecuador. OCP #2 (Papa) CALM[PDF：440KB] SOFEC designed and supplied two CALM Buoy systems for the OCP pipeline project in Ecuador. FPSO Fluminense External Turret[PDF：442KB] SOFEC designed, constructed and supplied an external cantilevered bow turret mooring system for a 357,000 dwt FPSO vessel to produce the Bijupirá & Salema fields in the Campos Basin, Brazil. Vehop CALM[PDF：234KB] SOFEC designed and constructed a CALM system located in 25m water depth to export diluted or refined crude oil and gas oil products to the 96,920 dwt tanker and import naphtha diluent from tankers to shore. FSO Ta’Kuntah External Turret[PDF：357KB] The FSO Ta’Kuntah is a MODEC converted 357,000 dwt ULCC tanker with a SOFEC external turret mooring system FPSO Terra Nova Internal Disconnectable Turret[PDF：360KB] SOFEC designed and engineered an internal disconnectable turret system in the Terra Nova FPSO. FPSO Petrobras P31 Internal Permanent Turret[PDF：370KB] SOFEC designed and constructed an internal permanent turret mooring system for a 283,000 dwt deepwater FPSO located in the Albacora field of the Campos Basin offshore Brazil. FPSO Petrobras P34 Internal Permanent Turret[PDF：542KB] SOFEC designed and constructed an internal permanent turret for a deepwater FPSO installed on the Barracuda and Caratinga fields offshore Brazil. CFE #2 CALM[PDF：363KB] SOFEC designed and fabricated a second CALM system for import of refined products for power generators in Mexico. St. Eustatius CALM[PDF：346KB] SOFEC designed, constructed, and installed a CALM system for crude oil import and product export as part of a trans-ship-ment terminal facility. CFE #1 CALM[PDF：410KB] The SOFEC CALM system was designed and fabricated to import heavy fuel oil feedstock for a power plant. RA-DE SALM® – Units #2 – #7[PDF：397KB] SOFEC designed, fabricated and tested each of these units to identical specifications. Various critical components are completely interchangeable to simplify logistical support requirements. HIRI CALM[PDF：293KB] SOFEC designed, constructed and installed a CALM terminal for crude oil, bunker fuel, gasoil, kerosene and gasoline and fuel oil. RA-DE SALM® – Unit #1[PDF：392KB] This unique Rapid Depolyment SALM (RA-DE SALM®) was developed based on SOFEC commercially available SPM technology. Palenque CALM[PDF：305KB] SOFEC designed, constructed and delivered a replacement CALM for crude oil import. LOOP #102, #103 & #104 SALMs®[PDF：293KB] SOFEC designed, constructed, and supervised installation of the SPM #102, SPM #103 and SPM #104 SALMs for unloading tankers up to the ULCC for the first domestic deep-water “superport”. FSOU HYSYS121 Disconnectable Internal Turret[PDF：467KB] SOFEC has been awarded the Lufeng Permanent Reinstatement Project Provision of Turret System by CNOOC China Limited. The system is a Disconnectable Turret System that will be integrated into a replacement FSOU and moored to the existing Lufeng 13-2 Field Moorings in the South China Sea. FSO Benchamas 2 External Turret[PDF：302KB] SOFEC designed, constructed, fabricated and installed an External Turret and Turret Support Structure for the Benchamas 2 FSO. The Benchamas Field is located offshore in the Bay of Thailand in approximately 71m water depth. FSO North Malay External Turret[PDF：239KB] SOFEC designed, constructed, fabricated and will install an External Turret and Turret Support Structure for the Hess North Malay Basin FSO. Ngih Son CALM Buoy[PDF：527KB] SOFEC designed, constructed and supplied a Catenary Anchor Leg Mooring (CALM) Buoy system for the Nghi Son Refinery and Petrochemical project located about 200 kilometers (120 mi) south of Hanoi in Tinh Gia District of Thanh Hóa Province PFLNG SATU External Turret[PDF：448KB] SOFEC designed, constructed, fabricated and delivered an external mooring system complete with anchor chains and anchor piles. PFLNG 2 DUA External Turret[PDF：362KB] SOFEC designed, constructed, fabricated and delivered an external mooring system complete with anchor chains and anchor piles. PGN FSRU Lampung Tower Yoke[PDF：273KB] SOFEC designed, constructed, and fabricated the HOEGH Tower Yoke Mooring which is a development of an LNG Floating Storage and Regasification Unit [FSRU] and associated facilities located near Labuhan Maringgai, Indonesia. FSO Gagak Rimang Tower Yoke[PDF：451KB] SOFEC designed and procured a tower yoke mooring system for the Cepu oil and gas block located near Bojonegoro, East Java, Indonesia. FPSO HYSY113 Tower Yoke[PDF：368KB] SOFEC designed and procured a tower yoke mooring system for the HYSY113 FPSO. FSO Erawan External Turret[PDF：434KB] Under contract to IHI Corporation, SOFEC was responsible for the design and construction of an external turret system and flexible riser system. SOFEC’s responsibilities included the design of the subsea pile-based pipeline end manifold (PLEM) and turret support structure (TSS). Malampaya CALM[PDF：530KB] SOFEC designed, constructed, and installed a CALM Buoy system for the SHELL Malampaya Deep Water Gas to Power project. PNG – Kumul Marine CALM[PDF：555KB] SOFEC designed, constructed, and supplied one (1) Catenary Anchor Leg Mooring (CALM) system for Oil Search Limited to be installed in the Gulf of Papua, Papua New Guinea. Nagarjuna CALM[PDF：510KB] SOFEC designed, constructed, and supplied one (1) Catenary Anchor Leg Mooring (CALM) system for Nagarjuna Oil Corporation Limited (NOCL) to be installed in the southeast coastal waters of India, 24km south of the town of Cuddalore, in Tamil Nadu state. FPSO Armada TGT I External Turret[PDF：462KB] SOFEC designed, constructed, fabricated and supplied an external turret mooring system for Hoang Long Joint Operating Company (HLJOC), a partnership comprising of Petrovietnam, Soco International, PTTEP and OPECO. Pertamina 150 CALM[PDF：426KB] SOFEC will design, supply and install two Catenary Anchor Leg Mooring (CALM) systems for Inti Karya Persada Tehnik (IKPT) near the Tuban field, offshore Indonesia. Pertamina 035 CALM[PDF：487KB] SOFEC will design, supply and install two Catenary Anchor Leg Mooring (CALM) systems for Inti Karya Persada Tehnik (IKPT) near the Tuban field, offshore Indonesia. Bina Refinery (BORL 1) CALM[PDF：524KB] SOFEC will designed, supplied and installed a Catenary Anchor Leg Mooring (CALM) system for the Bharat Oman Refinery project in the Bina Refinery field, on Indias northwest coast. FPSO Pyrenees Venture Internal Disconnectable Turret[PDF：547KB] SOFEC designed, constructed and supplied a disconnectable internal turret mooring system to moor a 148,500 dwt MODEC converted Aframax FPSO in 200m water depth. FPSO Song Doc Pride MV19 Spread Mooring[PDF：468KB] SOFEC designed and supplied a spread mooring system to moor a MODEC-owned 62,000 dwt FPSO. This vessel is located in Block 46/02 of the Song Doc field approximately 170km offshore Vietnam. FSO Rang Dong MV17 External Turret[PDF：263KB] SOFEC designed, constructed and supplied an external turret mooring system to moor a 52,000 dwt MODEC-newbuild FSO in 60m water depth. FPSO Stybarrow Venture MV16 Internal Disconnectable Turret[PDF：705KB] SOFEC designed, constructed and supplied a disconnectable internal turret mooring system to moor a 150,000 dwt MODEC-newbuild FPSO in 825m water depth. FSO Rong Doi MV12 External Turret[PDF：240KB] SOFEC designed and constructed an external turret mooring system to moor a 45,000 dwt MODEC-newbuild FSO located approximately 320km off the Nam Con Son Basin, Vietnam. FPSO Jasmine Venture MV7 External Turret[PDF：562KB] This SOFEC external turret mooring system was designed, constructed and supplied for the MODEC-owned “Buffalo Venture” FPSO from December 1999 to December 2004 when operations of the FPSO expired. FPSO MODEC Venture MV11 Internal Disconnectable Turret[PDF：431KB] SOFEC designed and constructed a disconnectable internal turret mooring system to moor a 150,000 dwt MODEC-converted FPSO in 156m water depth. FPSO Cuulong MV9 External Turret[PDF：482KB] SOFEC designed and constructed an external turret mooring system to moor the 149,500 dwt MODEC purpose-built FPSO. FSO Pathumabaha External Turret[PDF：442KB] SOFEC designed and constructed an external turret mooring system for a MODEC purpose-built 60,000 dwt FSO in 78m water depth in the Bongkot Gas Field, Gulf of Thailand. FPSO BOHAI SHI JI Tower Yoke[PDF：237KB] SOFEC designed and provided project management for a tower yoke mooring system for a new 172,000 dwt purpose-built double-hull vessel. FPSO Langsa Venture MV8 Spread Mooring[PDF：517KB] SOFEC designed and supplied the spread mooring anchor lines, onvessel chain support and installation equipment for the 35,000 dwt MV8 Langsa Venture FPSO for MEDCO MOECO Langsa Ltd. Malampaya CALM[PDF：449KB] SOFEC designed, constructed, and installed a CALM Buoy system for the SHELL Malampaya Deep Water Gas to Power project. FSO Vietsovpetro-01 External Turret[PDF：543KB] SOFEC designed, constructed and supplied an external turret mooring system for a MODEC purpose built 150,000 dwt FSO in 47m water depth in the White Tiger field. RAVVA CALM[PDF：412KB] SOFEC supplied a 12.5m diameter CALM buoy from its stock buoy program to replace a non-SOFEC® buoy that had experienced premature failure in service. FPSO Nexan Buffalo External Turret[PDF：313KB] SOFEC designed, constructed and supplied an external turret mooring system for a MODEC-converted 103,000 dwt FPSO in BHP Petroleum’s Buffalo oil field, located in Western Australia’s sector of the Timor Sea. Terrenganu #2 CALM[PDF：235KB] Designed, constructed and installed a replacement CALM system to accommodate 35,000 to 85,000 dwt tankers in 20m water depth. The system is linked via four 18-in. pipelines to a refinery located two miles away. FPSO Whakaaropai External Turret[PDF：576KB] SOFEC designed and constructed an external cantilevered bow turret for a MODEC-converted 135,510 dwt FPSO in 110m water depth. The facility is classed by Lloyd’s Register of Shipping. FPSO Nan Hai Sheng Li Internal Permanent Turret[PDF：505KB] SOFEC designed, constructed, and installed an internal permanent turret mooring system for the MODEC-converted 140,000 dwt Nan Hai Sheng Li FPSO. Pagerungan CALM[PDF：483KB] SOFEC designed, constructed and delivered a CALM system for condensate loading for the 350 MMscfd Pagerungen Besar Island Gas Field Development Project offshore Pagerungan in the Kangean Islands, Indonesia. FSO Nan Hai Sheng Kai Internal Disconnectable Turret[PDF：579KB] SOFEC designed and constructed an internal disconnectable turret mooring system to moor a MODEC-converted 121,361 dwt FSO vessel in the typhoon alley area offshore People’s Republic of China. CPC Ta Lin Pu #4 CALM[PDF：526KB] SOFEC designed and constructed the complete CALM terminal with a dual product swivel for the Talinpu Refinery at Kaohsiung, Taiwan. CPC Ta Lin Pu #3 CALM[PDF：253KB] SOFEC designed and constructed a CALM buoy system for crude oil import and bunker fuel export. Hazira CALM[PDF：244KB] SOFEC designed and constructed a CALM terminal for LPG and NGL service. FPSO Anoa Natuna External Turret[PDF：518KB] SOFEC designed and constructed an external turret-type SPM system for the Anoa Natuna, which was MODEC’s first purpose-built FPSO system. FPSO Perintis External Turret[PDF：266KB] SOFEC designed and constructed an external cantilevered turret mooring system for a permanently moored FPSO conversion. JNOC – FOSCO SALM®[PDF：514KB] SOFEC designed, constructed, and supervised installation of a second SALM terminal for strategic crude oil storage facility. JNOC – MOOS SALM®[PDF：422KB] SOFEC designed, constructed, and supervised installation of the first SALM terminal for strategic crude oil storage facility. Terrengganu #1 CALM[PDF：334KB] SOFEC designed and constructed a multi-product CALM terminal and two PLEMs and also designed the four 18-in. pipelines, which link the terminal to a refinery two miles away. Bataan SALM®[PDF：458KB] SOFEC designed, fabricated, and installed a SALM terminal in Manila. Tembungo SALM®[PDF：527KB] The Tembungo terminal was the flagship of SOFEC SALMs. Installed in 1974, the terminal operated continuously through the late 1980’s. FSO Aisla Permanent Internal Turret[PDF：535KB] SOFEC designed, constructed, fabricated and installed a permanent internal turret for the FSO Ailsa (Maersk Culzean). Butinge 2 CALM[PDF：484KB] Muzeiliu Nafta Butinge terminal purchased and installed a replacement buoy for their terminal operations in the Baltic Sea. Butinge CALM[PDF：484KB] SOFEC designed and constructed a CALM system to accommodate a 96,920 dwt tanker for operation in a cold weather environment. NAM F3-FB Monotower[PDF：325KB] This project included the design and construction of a hydraulically power driven, rotating assembly consisting of main bearing unit, fluid swivel and electrical swivel for an oil loading monotower. DDCS SALM®[PDF：220KB] SOFEC designed, constructed, and supervised installation of a SALM to operate in ice-laden water to import fuel, diesel and Mogas. CAMPSA SALM®[PDF：357KB] SOFEC designed, constructed, and installed a SALM terminal to import heavy fuel oil for distribution in North west Spain. Jazan CALM Buoys[PDF：731KB] SOFEC designed, constructed and supplied two Catenary Anchor Leg Mooring (CALM) Buoy systems for Saudi Arabian Oil Company to be installed in Jazan, Saudi Arabia. SEPOC RAS ISSA CALM Buoy[PDF：460KB] SOFEC designed, constructed, fabricateed and installed a Catenary Anchor Leg Mooring (CALM) Buoy System. Mina al Ahmadi #1 and #2 CALMs[PDF：474KB] SOFEC will redesign the existing CALM buoy piping systems and upgraded the design pressure rating of the two Kuwait Oil Company CALM Buoys. Jebel Dhanna #2 CALM[PDF：240KB] SOFEC designed, constructed, and installed a CALM Buoy system to accommodate up to 450,000 dwt tankers. Jebel Dhanna #1 CALM[PDF：266KB] SOFEC designed, constructed, and installed a CALM Buoy system to accommodate up to 450,000 dwt tankers. ADMA OPCO CALM[PDF：252KB] SOFEC designed, constructed, and installed a CALM terminal for crude oil exports at the Tanker Berth No. 3, Das Island, Abu Dhabi, United Arab Emirates. FSO Safer External Turret[PDF：328KB] SOFEC developed, designed and constructed an external turret-type SPM system for a 409,000 dwt tanker that serves as an FSO terminal for crude oil. Ju’Aymah #34 & #35 SALMs®[PDF：465KB] SOFEC designed, constructed, and supervised installation of two SPMs for 750,000 dwt tanker (ULCC’s).
